Product Details
Backflow_Preventer-RPDA-Zurn_Wilkins-Model_475DAVBGVIC_Grooved-(8-10_Inch)
Category
Pipe Accessories
Description
| Property | Value |
|---|---|
| Shut Off Valve | 8" |
| Product data url | |
| Description | RPDA Reduced Pressure Principle Detector Assembly |
| Product Install & Maintenance Sheet URL | |
| Product Page URL | |
| URL | |
| Weight | 543 lbs. (246.3kg) |
| Main Body DA | 8" |
| Standards Compliance | ASSE, FCCCHR@USC, UL, C-UL, FM |
| Specification Sheet URL | |
| Model | 475 DAVBGVIC |
| Manufacturer | Zurn Wilkins |
| Type Comments | Grooved Connections AWWA C606 - Steel |
| Application | Potable water lines in fire systems. Designed for installation on potable water lines in fire protection systems to protect against both backsiphonage and backpressure of contaminated water into the potable water supply. |
| Repair Parts URL | |
| Assembly Code | D2090800 |
| Property | Value |
|---|---|
| Hydrostatic Test Pressure | 350 lb/(in^2) |
| Flow | 0 |
| Rated Flow | 1600 (gal)/min |
| Max Working Water Pressure | 175 lb/(in^2) |
| Max Working Water Temperature | 140 degF |
| Pressure Loss at Rated Flow | 15 lb/(in^2) |
| Property | Value |
|---|---|
| Nominal Diameter | 8 in |
| Overall Length | 30.3125 in |
| Length | 30.3125 in |
| Height | 46.3125 in |
| Overall Height | 46.3125 in |
| Property | Value |
|---|---|
| Bend Radius | 1.25 in |
| Nominal Radius | 4 in |
| Bend Radius Outside | 2 in |
| Symbol Length | 0.25 in |
| Property | Value |
|---|---|
| Use Annotation Scale |
