| DimC | 0.1354 ft |
| URL | View |
| Flow Factor | 1 |
| Standards Compliance | ASSE, IAPMO, CSA, City of LA, NSF/ANSI 61 |
| Tail | 0.1667 ft |
| DimB | 0.6042 ft |
| DimC Strainer | 0.1667 ft |
| Bell Radius | 0.1406 ft |
| Model | 625XL |
| Product Install & Maintenance Sheet URL | View |
| Weight | 5 |
| Product Page URL | View |
| Bell Height | 0.0521 ft |
| Hex Height | 0.0833 ft |
| Bolt Length | 0.1146 ft |
| Hex Radius | 0.0833 ft |
| Repair Parts URL | View |
| Bell Top Radius | 0.0521 ft |
| Application | This valve directly replaces a single union competitor model
25AUB. Ideal for use where Lead-Free* valves are required.
Designed for installation on potable water lines to reduce high
inlet pressure to a lower outlet pressure. The integral strainer
makes this device most suitable for residential and commercial
water systems requiring frequent cleaning because of sediment
and debris. The direct acting integral by-pass design prevents
buildup of excessive system pressure caused by thermal expansion.
The balanced piston design enables the regulator to react
in a smooth and responsive manner to changes in system flow
demand, while at the same time, providing protection from inlet
pressure changes. |
| Fall Off | See Specification Sheet for Fall Off Curve |
| Stainer CL | 0.1667 ft |
| Factory Preset Pressure | 50 lb/(in^2) |
| Manufacturer | Zurn Wilkins |
| Bolt Radius | 0.0156 ft |
| Specification Sheet URL | View |
| Bolt H Radius | 0.0313 ft |
| Cap Radius | 0.0635 ft |
| DimA | 0.5 ft |
| Description | Lead-Free* Pressure Reducing Valve |
