765c2b26-7c96-4d3e-bed8-f8be73b32824 - 3D View - Preview.png

2 1/2"

Introducing our exquisite collection of featured doors, meticulously crafted to redefine elegance and sophistication. Each door in this extraordinary lineup is a testament to our unwavering commitment to exceptional craftsmanship and unparalleled quality.

Featured

Contact Sales Rep

Richly detailed architectural design in a classic style.

Memoirs®

A fresh twist on simple, Shaker-style furniture design.

Tresham®

An alluring blend of craftsman furniture and fine jewelry.

Archer®

Consider a Nested single, distinctive style for total harmony

Explore Nested Collections

Consider a single, distinctive style for total harmony

Explore Collections

memoirs

tresham

Explore Nested Series

SHADOW TONES, SKY TONES, BUILDING STONE, SQUARES & RECTANGLES

Modern commercial building architectural stone veneer healthcare clinic – Buff Gray Tailored Blend

ARCTIC TONES, BUILDING STONE, SQUARES & RECTANGLES

Commercial modern architectural stone veneer healthcare clinic – Fond du Lac Country Squire & Jumpers Custom Blend

HONEY TONES, SHADOW TONES, BUILDING STONE, SQUARES & RECTANGLES

Craftsman tan blue stone veneers exterior wood beam patio interior design entrance – Spalted Oak Ashlar

ARCTIC TONES, LANDSCAPE STONE, IRREGULAR, SQUARES & RECTANGLES

Backyard landscaping outdoor patio furniture fire pit – Fond du Lac stone pavers steppers flagstone steps

ARCTIC TONES, BUILDING STONE, CUT STONE, CUSTOM CUT STONE, SQUARES & RECTANGLES

Fond du Lac Tailored Blend and Indiana Silverbuff Cut Stone

Brag Book

Designing with GDF Studio couldn’t be easier. Grab the files you need and load them into your project.

The single source of truth for interior products

GDF AEC Portal Studio

Find BIM, CAD and other technical product information for products found in our catalog.

Add products to your project and receive a detailed Project Submittal.

Add products to your project and get a comprehensive report for all available LEED credits.

Property	Value
Hand Wheel Radius	0.6823 ft
OSY
Symbol Width	0.3127 ft
Hand Wheel Height	1.901 ft
Assembly Code	D2090800
Product Page URL	View
Horizontal Flange Height	1.013 ft
Flange Radius	0.6667 ft
Description	Lead-Free* Resilient Wedge Gate Valve, Outside Stem and Yoke (OS&Y)
Symbol Extension Length	0.0833 ft
Application	Designed for installation on Potable water lines, Irrigation systems, Waterworks connections, and Fire systems.
URL	View
Closed Height	2.8958 ft
Type Comments	Flanged Connections ANSI B16.1 Class 125
Flange Thickness	0.099 ft
Spoke Width	0.6198 ft
Specification Sheet URL	View
Housing Top Radius	0.1979 ft
Housing Bottom Radius	0.2083 ft
Model	48OSYG
Cover Diameter	0.625 ft
Body Length	1.0833 ft
Standards Compliance	UL, C-UL, FM, AWWA, NSF 61-G
Product data url	View
Horizontal Flange Thickness	0.1589 ft
Hand Wheel Diameter	1.3646 ft
Weight	290 lbs (132 kg)
Open Height	3.8021 ft
Manufacturer	Zurn Wilkins

Property	Value
Max Working Water Temperature	140 degF
Flow	0
Max Working Water Pressure	200 lb/(in^2)
Rated Flow	2300 (gal)/min
Pressure Loss at Rated Flow	0.04 lb/(in^2)
Hydrostatic Test Pressure	400 lb/(in^2)

Property	Value
Nominal Radius	0.4167 ft
Body Diameter	0.9167 ft
Body Radius	0.4583 ft

Property	Value
Nominal Diameter	0.8333 ft
Length	1.0833 ft
Flange Diameter	1.3333 ft
