Product Details
Tempering_Mixing_Valve-Zurn_Wilkins-Model_ZW1017PEX_Barb-(0.5-0.75_Inch)
Category
Pipe Accessories
Description
| Property | Value |
|---|
| Property | Value |
|---|---|
| Weight | 2 lbs. / 1 kg |
| BodyR | 0.0677 ft |
| Specification Sheet | |
| Instruction Sheet | |
| Max. Working Pressure (Dynamic) | 1.5-70 psi |
| Flow Rate @ 45 psi Pressure Loss | 18 gpm |
| Standards Compliance | ASSE® Listed 1017, CSA® Certified |
| Min. Flow Rate | 0.5 gpm |
| URL | |
| Outlet Temperature Range | 95-131°F |
| Temperature Cold Supply | 40-75°F |
| Set Temperature Accuracy | +/-4°F |
| CapL | 0.099 ft |
| Max. Working Pressure (Inlet) | 145 psi |
| Model | 12-ZW1017PEX |
| DimB | 0.2917 ft |
| Product Page URL | |
| Temperature Hot Supply | 120-195°F |
| NomRad | 0.0208 ft |
| Product data url | |
| DimA | 0.4635 ft |
| CapR | 0.0729 ft |
| Manufacturer | Zurn Wilkins |
| Description | Aqua-Gard Tempering Mixing Valve |
| Assembly Code | D2090800 |
| DimC | 0.4635 ft |
| Nominal Size | 0.5 in |
| Property | Value |
|---|---|
| Use Annotation Scale |
Product Resource download links.
