| Product data url | View |
| Test Cock Boss length | 0.0951 ft |
| Product Page URL | View |
| Rated Flow | 100 (gal)/min |
| Hydrostatic Test Pressure | 350 lb/(in^2) |
| Body Radius | 0.0833 ft |
| Standards Compliance | ASSE, FCCCHR@USC, IAPMO, CSA, AWWA, NSF 61-G |
| Product Install & Maintenance Sheet URL | View |
| Max Working Water Temperature | 180 degF |
| Flow | 0 (gal)/min |
| Repair Parts URL | View |
| Check Top Radius | 0.0583 ft |
| Flow Factor | 1 |
| Handle Length | 0.3958 ft |
| Assembly Code | D2090800 |
| Pressure Loss at Rated Flow | 8 lb/(in^2) |
| Test Cock Radius | 0.0286 ft |
| Application | Designed for installation on potable water lines to protect against both backsiphionage and backpressure of polluted water into the potable water supply. |
| URL | View |
| Nominal Diameter | 0.125 |
| Max Working Water Pressure | 175 lb/(in^2) |
| Main Body Length | 1.1458 ft |
| Weight | 22 lbf |
| Description | Lead-Free* DC Double Check Valve Assembly |
| Model | 950XLT2 |
| Nominal Radius | 0.0625 |
| Manufacturer | Zurn Wilkins |
| Specification Sheet URL | View |
