Product Details
Ceiling_Panel-CertainTeed-2x4-Sand_Micro-SHM-194
Category
Ceilings
Description
| Property | Value |
|---|---|
| Nominal Thickness | 0.0521 ft |
| Edge Profile | Reveal |
| Suspension Sys | CertainTeed Ceilings |
| Property | Value |
|---|---|
| Type Image | <None> |
| Keynote | |
| Model | SHM-194 |
| Manufacturer | CertainTeed Ceilings |
| Type Comments | |
| URL | |
| Description | 2x4 Reveal Edge |
| Assembly Description | Suspended Ceilings - Acoustical |
| Assembly Code | C3030210 |
| Type Mark | |
| Cost | 0 |
| Subcategory | Mineral Fiber |
| Manufacturer Address | 20 Moores Rd. Malvern, PA 19355 |
| Manufacturer Email | |
| Manufacturer Phone | 610.341.7000 |
| Manufacturer Toll Free Phone | 800-446-5284 |
| 04 CSI | 09 51 00 |
| OmniClass Code | 23.35.70.24.11 |
| OmniClass Title | Suspended Ceilings |
| Product Page URL | |
| Installation URL | |
| ecoScorecard_data | |
| Cost Info | |
| Image | <None> |
| Comments | |
| Mark | |
| 95 CSI | 9510 |
| Property | Value |
|---|---|
| Technical Information | https://www.certainteed.com/resources/CTC_Sand_Micro_Sand_Micro_Customline_DataPage.pdf |
| Warranty | 10 year 104/90 Limited Warranty |
| Property | Value |
|---|---|
| Humidity/Sag Resistance | |
| Acoustics - NRC | 0.5 |
| Acoustics - CAC | 33 |
| Acoustics - AC | N/A |
| Light Reflectance Average | 0.88 |
| Anti-Microbial | BioShield standard |
| VOC Formaldehyde | Compliant |
| ASTM E 1264 Type | II |
| ASTM E 1264 Pattern | C E |
| ASTM E 1264 Form | 2 |
| ISO Sound Absorption Class |
| Property | Value |
|---|---|
| Mold Resistant | BioShield |
| Washable | |
| Scrubbable | |
| Scratch Resistant | |
| High Durability | |
| Room Bounding | |
| Level | Level 1 |
| Height Offset From Level | 8 ft |
| Property | Value |
|---|---|
| Phase Created | New Construction |
| Phase Demolished |
| Property | Value |
|---|---|
| Material | Mineral Fiber |
| Different Colors Available | |
| Texture | Light Textured |
| Surface-Finish | Painted |
| Property | Value |
|---|---|
| Nominal Length | 4 ft |
| Nominal Width | 2 ft |
| Grid Face | 0.0781 ft |
| Square Feet/Carton | 64 sqft |
| Slope | 0 rise_over_in |
| Area | 32 sqft |
| Perimeter | 24 ft |
| Weight per Carton | 52 lbf |
| Property | Value |
|---|---|
| Fire Rating | Class A |
| Flame Spread Index | ≥25 |
| Smoke Developed Index | ≥50 |
| Property | Value |
|---|---|
| R-Value | 1.51 |
| Property | Value |
|---|---|
| Heat Transfer Coefficient (U) | 0 btu/(h*sqft*degF) |
| Thermal Resistance (R) | 0 (h*(sqft)*degF)/btu |
| Thermal mass | 0 btu/degF |
| Absorptance | 0.1 |
| Roughness | 1 |
Product Resource download links.
