| Relief Valve Depth | 0.3229 ft |
| Application | Potable water line backflow prevention. Designed for installation on potable water lines to protect against both backsiphonage and backpressure of contaminated water into the potable water supply. |
| Valve Width | 0.2448 ft |
| URL | View |
| Max Working Water Pressure | 175 lb/(in^2) |
| Product Install & Maintenance Sheet URL | View |
| Manufacturer | Zurn Wilkins |
| Pressure Loss at Rated Flow | 17 lb/(in^2) |
| Handle Half Length | 0.4896 ft |
| Valve Position | 0.0521 ft |
| Repair Parts URL | View |
| Max Working Water Temperature | 180 degF |
| Product Page URL | View |
| Hydrostatic Test Pressure | 350 lb/(in^2) |
| Specification Sheet URL | View |
| Weight | 5.7 lbs. (2.6 kg) |
| Half Valve Width | 0.1875 ft |
| Assembly Code | D2090800 |
| Product data url | View |
| Standards Compliance | FCCCHR@USC, ASSE, CSA, IAPMO, AWWA |
| Symbol Width | 0.0208 ft |
| Nominal Radius | 0.03125 |
| Rated Flow | 30 (gal)/min |
| Nominal Diameter | 0.0625 |
| Description | RP Reduced Pressure Principle Assembly |
| Model | 375 |
| Body Length | 0.7292 ft |
| Type Comments | Threaded connections ANSI B1.20.1, female |
