| Seal Length | 0.1615 ft |
| Test Cock Position | 0.0417 ft |
| Application | Designed for installation on potable water lines to protect against both backsiphionage and backpressure of contaminated water into the potable water supply. |
| Valve Test Cock Position | 0.4271 ft |
| Overall Check Height | 0.276 ft |
| Specification Sheet URL | View |
| Description | Lead-Free* RP Reduced Pressure Principle Assembly |
| Test Cock Head | 0.0537 ft |
| Model | 975 XL2 |
| Pin Radius | 0.0417 ft |
| Handle Length | 0.2708 ft |
| Handle Height | 0.1458 ft |
| Curve | 0.1667 ft |
| Test Cock Length | 0.25 ft |
| Repair Parts URL | View |
| Max Working Water Pressure | 175 lb/(in^2) |
| URL | View |
| Standards Compliance | FCCCHR@USC, ASSE, IAPMO, CSA, AWWA, NSF 61-G |
| Pressure Loss at Rated Flow | 14.3 lb/(in^2) |
| Rated Flow | 30 (gal)/min |
| Hydrostatic Test Pressure | 350 lb/(in^2) |
| Test Cock Radius | 0.0313 ft |
| Handle Width | 0.1042 ft |
| Max Working Water Temperature | 180 degF |
| Relief Valve Bottom | 0.4167 ft |
| Manufacturer | Zurn Wilkins |
| Body Radius | 0.0749 ft |
| Symbol Length | 0.1146 ft |
| Nominal Diameter | 0.0625 |
| Weight | 12 lbs., 5.5 kg |
| Body Length | 0.6458 ft |
| Check Radius | 0.125 ft |
| Type Comments | Female Threaded NPT Connections ANSI B1.20.1 |
| Nominal Radius | 0.375 |
| Product data url | View |
| Product Install & Maintenance Sheet URL | View |
| Flow | 0 (gal)/min |
| Product Page URL | View |
| Adapter Radius | 0.0625 ft |
| Valve Test Cock Length | 0.207 ft |
| Adapter Length | 0.0625 ft |
| Assembly Code | D2090800 |
| Check Length | 0.2891 ft |
| Valve Body Length | 0.1563 ft |
| Handle Position | 0.099 ft |
| Overall Check Depth | 0.25 ft |
| Valve Position | 0.0781 ft |
