| Pipe Vertical Position | 6.25 in |
| Pipe Size | 1 in |
| Main Body Width | 10.3008 in |
| Specification Sheet URL | View |
| Type Comments | Grooved Connections AWWA C606 |
| Hydrostatic Test Pressure | 350 lb/(in^2) |
| URL | View |
| Main Body | 6" |
| Description | Lead-Free* DC Double Check Valve Assembly |
| Symbol Length | 0.25 in |
| Repair Parts URL | View |
| Model | 450 BGVIC |
| Bend Radius | 1.25 in |
| Nominal Radius | 3 |
| Bend Radius Outside | 2.3984 in |
| Weight | 215 lbs. (97.5 kg) |
| Rated Flow | 1000 (gal)/min |
| Nominal Diameter | 6 |
| Manufacturer | Zurn Wilkins |
| Product Page URL | View |
| Max Working Water Pressure | 175 lb/(in^2) |
| Standards Compliance | UL, cUL, FM, FCCCHR@USC, ASSE, IAPMO, CSA, AWWA, NSF 61-G |
| Max Working Water Temperature | 140 degF |
| Pipe Position | 8.75 in |
| Application | Potable water line backflow prevention. Designed for installation on potable water lines to protect against both backsiphonage and backpressure of polluted water into the potable water supply. |
| Pressure Loss at Rated Flow | 4.7 lb/(in^2) |
| Flow | 0 (gal)/min |
| Product data url | View |
| Overall Height | 32 in |
| Product Install & Maintenance Sheet URL | View |
| Gate Valve | 6" |
| Assembly Code | D2090800 |
