| OmniClass Code | 23-27 31 00 |
| IFC Classification | Valve |
| Nominal Radius | 0.0625 |
| Product group | Valves |
| Region Antarctica | All |
| Weight | 21.5 lbs. (9.8 kg) |
| Specification Sheet URL | View |
| Nominal width | 0 |
| URL | View |
| NBS Reference Code | 94-94 |
| Repair Parts URL | View |
| Pressure Loss at Rated Flow | 11 lb/(in^2) |
| Valve Width | 0.5 ft |
| Nominal height | 0 |
| Description | Lead-Free* RP Reduced Pressure Principle Assembly |
| Hydrostatic Test Pressure | 350 lb/(in^2) |
| Material main | Metal |
| Manufacturer name | Zurn Wilkins |
| UNSPSC Code | 401416 |
| Region Europe | All |
| Nominal Diameter | 0.125 |
| Region North America | All |
| Model | 375XL |
| Weight Net (Kg) | 0 |
| Product SKU | 375XL |
| Application | Potable water line backflow prevention. Designed for installation on potable water lines to protect against both backsiphonage and backpressure of contaminated water into the potable water supply. |
| Standards Compliance | FCCCHR@USC, ASSE, CSA, IAPMO, AWWA, NSF 61-G |
| Uniclass 1.4 Code | L7136 |
| Edition number | 1 |
| Region Oceania | All |
| Region South America | All |
| Max Working Water Temperature | 180 degF |
| Product family | Plumbing |
| Product Install & Maintenance Sheet URL | View |
| Max Working Water Pressure | 175 lb/(in^2) |
| Product data url | View |
| Product Guid | c1fddee3-facc-480c-aa41-14c0634503e0 |
| Test Cock Height | 0.2917 ft |
| Date of publishing | 4/1/2014 |
| Region Africa | All |
| QR code | http://bimobject.com/ZurnWilkins/product/375XL |
| Uniclass 1.4 Description | Valves |
| Manufacturer | Zurn Wilkins |
| Manufacturer country | United States |
| Type Comments | Threaded connections ANSI B1.20.1, female |
| BIMobject category | Other |
| OmniClass Description | Valves |
| Design country | United States |
| Body Length | 1.2708 ft |
| Technical description | View |
| Region Asia | All |
| NBS Reference Description | Valves |
| Region Middle East | All |
| Assembly Code | D2090800 |
| Symbol Length | 0.1719 ft |
| Product Page URL | View |
| Rated Flow | 100 (gal)/min |
