| Pressure Loss at Rated Flow | 7.7 lb/(in^2) |
| Weight | 3.0 lbs. (1.4 kg) |
| Assembly Code | D2090800 |
| Half Body Length | 0.5104 ft |
| Product Page URL | View |
| Body Length | 1.0208 ft |
| Nominal Radius | 0.0416666666666667 |
| Specification Sheet URL | View |
| Description | DC Double Check Valve Assembly |
| Product data url | View |
| Type Comments | Threaded connections ANSI B1.20.1, female |
| Hydrostatic Test Pressure | 350 lb/(in^2) |
| Tap Size | 0.0625 ft |
| Product Install & Maintenance Sheet URL | View |
| Valve Height | 0.2708 ft |
| Rated Flow | 50 (gal)/min |
| Repair Parts URL | View |
| Body Width | 0.3438 ft |
| URL | View |
| Test Cock Position | 0.237 ft |
| Model | 350 |
| Application | Potable water line backflow prevention. Designed for installation on potable water lines to protect against both backsiphonage and backpressure of polluted water into the potable water supply. |
| Body Radius | 0.0508 ft |
| Standards Compliance | FCCCHR@USC, ASSE, IAPMO, CSA |
| Nominal Diameter | 0.0833333333333333 |
| Manufacturer | Zurn Wilkins |
| Flow | 0 (gal)/min |
| Body Depth | 0.1458 ft |
| Half Body Width | 0.1719 ft |
| Symbol Width | 0.0625 ft |
| Max Working Water Pressure | 175 lb/(in^2) |
| Max Working Water Temperature | 140 degF |
