Product Details
Backflow_Preventer-RPDA-Zurn_Wilkins-Model_475DAVG_Grooved-(8-10_Inch)
Category
Pipe Accessories
Description
| Property | Value |
|---|---|
| Length | 30.3125 in |
| Overall Height | 56.5 in |
| Pipe Size | 1.0898 in |
| Overall Length | 30.3125 in |
| Height | 56.5 in |
| Nominal Diameter | 10 in |
| Property | Value |
|---|---|
| Assembly Code | D2090800 |
| Repair Parts URL | |
| Specification Sheet URL | |
| Standards Compliance | UL, C-UL |
| Weight | 1113 lbs. (504.8 kg) |
| Product Install & Maintenance Sheet URL | |
| Description | RPDA Reduced Pressure Principle Detector Assembly |
| Product Page URL | |
| Main Body DA | 10" |
| Application | Potable water lines in fire systems. Designed for installation on potable water lines in fire protection systems to protect against both backsiphonage and backpressure of contaminated water into the potable water supply. |
| Shut Off Valve | 10" |
| URL | |
| Product data url | |
| Model | 475 DAVG |
| Manufacturer | Zurn Wilkins |
| Type Comments | Grooved Connections AWWA C606 - Steel |
| Property | Value |
|---|---|
| Use Annotation Scale |
| Property | Value |
|---|---|
| Hydrostatic Test Pressure | 350 lb/(in^2) |
| Rated Flow | 2300 (gal)/min |
| Max Working Water Temperature | 140 degF |
| Flow | 0 |
| Max Working Water Pressure | 175 lb/(in^2) |
| Pressure Loss at Rated Flow | 14.5 lb/(in^2) |
| Property | Value |
|---|---|
| Bend Radius Outside | 2 in |
| Nominal Radius | 5 in |
| Symbol Length | 24 in |
| Bend Radius | 1 in |
